TagFlash ECU Programmer For 99% Car Truck Motorbike OBD BENCH BOOT BDM JTAG Mode Read TCU Chip Tuing Tool Free Dongle

Good NEWS :

Following 11 ECU Software download links as free gifts ( Values more than 500usd )

1.14G tuning files

(Database with more than 20.000 files for chip tuning. Originals, stage 1, stage 2 and stage 3 included. Stage 1 can increase 20% performance,stage 2 increase 40%, stage 3 increase 60%.)

2.Damos

(Damos isinstruction for Winols tofindmaps,only we can send such amazine gift )

3.Universal Immo Decoding

4.ECU Fault DTC Remover

5.ECM Titanium

6.WinOLS

7.2017 DPF/EGR/FLAP+CRACK+keygen

8.ECU maps

9.public-archivedwl

10.ECU Pinouts collection

11.ECU Safe

Notes :

1.TagFlash works online ,it can free update online , no need Annual Subscription. it also can work offline, but need to connect offline dongle to work . the package includes offline dongle !

2.You can click support list to check whether it can support your model !

3.Anti-virus and firewall must be closed before install software !

4.TagFlash is more powerful functions than KT200 ,supports more and newer models !

Tagflash Introduction:

TagFlash is a powerful ECU Programmer that enables the reading and programming of engine control units (ECUs) and transmission control units (TCUs) for various cars, trucks, motorcycles, Marine worldwide from Europe, USA, India, Asia, China etc.

It reads and writes EEPROM and flash memory of ECUs i.e Bosch, Marelli, Siemens, Ford, Delphi, Denso, Transtron, Delco, Continental,Motorola, Valeo, Siemens Continental etc.

TagFlash read/write ECU in the mode of OBD, on Bench, Boot mode, BDM, and Jtag systems.

Its versatility and broad compatibility make it a valuable tool for automotive technicians and enthusiasts.

TagFlash Highlights:

1.This new system developed with high-speed USB2.0 currently the fastest and safest production in the market.

2. It is easy to install and use by anyone.

3.The Driver will always be clickable, the options will not become gray.

4.Time synchronization is no need, it allows for some margin of error.

5.On bench mode, directly identify the chip type before reading/writing .

6.Stable to read / write eeprom & flash via OBD.

7.Reliable for checksum calculations.

8.Add speed limit off.

9.It is relatively up to date that the protocol is synchronized to the original tools.

10.It is not easy to damage the ecu. It can work directly if it can be written; if it cannot be written, it won’t be possible from the beginning.

11.There is no need to restart the software when the software reports an error, and there is a direct reset function in the option.

12.Support working in offline mode.

13. Synchronize Agreements Until April 1st, 2023

14. Stability/Comprehensive: Yes

15. Own Servers in Multiple countries

The product software includes 10 licenses: Car OBD, Truck OBD, Tractor/Marine OBD, Motorbike OBD, Full Mode, Recondition (remove speed), Tool Boot, Bench Mode,BDM/JTAG.

TagFlash Compatible Vehicles:

Car

Truck

Tractor/Marine

Motorbike

Read / Write ECU

Read /Write TCU (a part)

TagFlash is confirmed to read/write ECU on many ECU types such as:

DCM2.7AP yes

DCM2.7 yes

MD1CS018 possible: choose the chip type spc58 to read/write

sid208-sid209 read write on bench ok.

dcm7.1b can read via obd ok

dcm6.2v read via obd no problem

TagFlash is not able to read/write:

Sim2k260 NO

DCM7.1AP No

TagFlash Compatible Operation System:

Windows XP 32 64 bit

Windows Vista 32 64 bit

Windows 7 32 64 bit

Windows 8

Windows10

TagFlash Language:

Ltaliano, English, Deutsch, Francais, Espanol, Polish, Portugues, Czech, Romana, Turkish, Hungarian, Russian, Bulgarian, Chinese, Japanese, Korean and Serbian

·5/30V Car, Industrial vehicles, WP

·Boot Mode C167,ST10

·RS232 RS485

·CAN BUS V2.0 50 Kb>10 Nkb

·J1850 VPW PWM GM-FORD

·BDM MPC5XX

·BOOT MODE TRICORE

·Auto setup Pull up K-ine 250,500,1000 ohm

·Auto setup termination Can bus 0,60,120ohm

·Master

·Recovery mode

·Checksum automatic

Hardware product list:

Master x 1,
BENCH BOX x1,
OBD wires x 2,
Pinout line x 1,
BOM adapter x4 ,
Transfer cables x 3,
Power wire x 4,
Set of resistors x1,
Adapter plugs x 4 sets,
Power adapters x 5 sets

Take Care of This: When using TagFlash to read/write ECUvia OBD, must plugMini Gender Adapter.
Mini Gender Adapter is the yellow Adapter which comes in package (shown as below).
For OBD mode, use the Gender Adapter that cuts pins 3,8,9,11. This is essential for programming and reading via OBD.Using TagFlash in the car without the Gender Adapter, you risk to blow-up your adapter.
For BDM or JTAG mode, connect directly without the Gender Adapter.

Q: I can install in same pc.. Together with Kt200? Or we need KT200 uninstall..?

A: Yes, you can install both TagFlash and KT200 in same PC, but need to switch the driver.

Q: Does TagFlash support online VR reading/writing?

A: Sorry, not support.

Q: Does TagFlash offline mode need one extra offline dongle?

A: yes, it needs. it includes offline dongle .

Q: Will TagFlash be connected to the computer when installing the driver?

A: yes, it needs.
