V08 ELM327 Bluetooth 4.0 HW V2.2 PIC18F 25K80 OBD2 Car Diagnostic Scanner

Features:

Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database).
Function: Short Term Fuel Trim, Long Term Fuel Trim, Intake Manifold Pressure, Timing Advance, Intake Air Temperature, Air Flow Rate.
Display current sensor data, including: Engine RPM, Calculated Load Value, Coolant Temperature, Fuel System Status, Vehicle Speed.
Clear trouble codes and turn off the MIL.

Specifications:

Communication method: Bluetooth 4.0
Main control chip: PICI8F25K80
Software platform: support Android / Windows
Working voltage: 9V-16V
Working current: 35mA
Standby current: 25mA
Working temperature: -40C-85″C
Working humidity: less than 60%
Product size: 35*17*44mm
Product weight: 18.5g

Package included:

1 x Diagnosis Instrument

Note:

1.Due to the difference between different monitors, the picture may not reflect the actual color of the item.We guarantee the style is the same as shown in the picture.
2.Due to the manual measurement and different measurement methods, please allow 1-3cm deviation.Thanks!
