VC601 TPMS Tire Pressure Monitoring Alarming System Diagnostic-tool with Bluetooth 4.0 Work on Android IOS Ipad
Bluetooth 4.0 low energy TPMS description:
It was designed as a direct tire pressure monitoring system, namely, installing pressure and temperature sensor on the tire, thendisplaying the real-time data on phone (Android , IOS, IPad) through Bluetooth connection, And it will alarm when the tire pressure and temperature is abnormal.
APP Program Feature:
1. Quick leak alarming: when pressure leaks over 5kpa within 5 seconds, it will start up quick leak alarming and appear a “leak” icon.
2. Slow leak alarming: when tire pressure is lower than the limited pressure, it will start up slow leak alarming and appear a “low pressure” icon.
3. High pressure alarming: when pressure is over the limited tire pressure, it will start up high pressure alarming
4. Low pressure alarming: when pressure is lower than the limited tire pressure, it will start up low pressure alarming
5. High temperature alarming: When tire temperature is over the limited temperature, it will start up high temperature alarming
6. No signal alarming: when cannot receive signal in a certain period of time, it will start up no signal alarming
7. Low battery power alarming: When battery is lower than the setting data, it will start up low battery power alarming
Data Displaying:
Setting:
Specifications:
Operating voltage:3V
Operating currant:100μA
Static current:≤ 2.2μA
Bluetooth transmit power:0dBm MAX
Responding time:≤ 5s
Display way:by APP
Waterproof level:IP67
Working humidity:95% MAX
MAX Tire Pressure Monitor range:100-1300kPa
Tire Pressure Monitor Accuracy: ± 10kPa
Tire Temperature Monitor Accuracy:± 3ºC
Working temperature:-30ºC~ +80ºC(external sensor)
Working temperature:-40ºC~ +85ºC(built-in sensor)
Storage temperature:-30ºC~ +85ºC(external sensor)
Storage temperature:-45ºC~ +125ºC(built-in sensor)
Battery capacity:140mAh(external sensor)
Battery capacity:330mAh(built-in sensor)
Battery life:about 400 days(external sensor, calculated by 4h driving each day)
Battery life:about 1200 days(built-in sensor)
Weight:8g±1g(external sensor)
Weight:30g±1g(built-in sensor)
