XTOOL ASD60 OBD2 Scanner For VW Full Systems Diagnostic VAG COM 19.6 Free Update Software For Android/IOS
Top Reason our ASD60 is the best choice for your car
1. ASD60 can support full system diagnosis of single vehicle type for VW, SEAT, SKODA
2. ASD60 can support 19 kinds of special functions like Oil/Service/Maintenance Light, ABS bleeding… and etc.
3. ASD60 can support program the hidden function and action test.
4. ASD60 can support full OBD2 functions.
5. ASD60 software get free update with life time no any extra cost again ,we will add more functions in the app.
6. ASD60 device has 3 years warranty and lifetime tech support.
7. ASD60 can support multi language, just choose the language in the setting is ok.
Wide Car Support:
ASD60 can support for VW, for SEAT and for SKODA most cars from 1996 to 2021(not a device can support all cars), and we keep updating to support more cars.
ASD60 can support full system diagnosis for single vehicle type
1.To diagnose Engine System if your engine get any error code and any problems with
2.To diagnose Airbag System if you Feel the Airbag will not pop up automatically, and with the error codes onside the ez400pro can read the error codes and help you fix it
3.To diagnose Brake System if you feel the brake pedal is mushy and notice unusual odor or noise, etc. A properly operating brake system is critical to ensure safe vehicle control and operation;
4.To diagnose Emission System if the system is affected by vehicle age or poor quality fuel. A good emission system reduces harmful gases to a large degree and protects you from being fined;
5.To diagnose Fuel system if vehicle won’t start or “Check Engine” light is illuminated. Check car’s fuel system regularly ensures the best performance of your car with the lowest emissions;
6.To diagnose Transmission if your car is slipping or difficult to shift. The system plays an important part in the overall performance of your car;
7.To diagnose Wiper System if you observe chattering or streaking wiper. If the car is not regularly checked, the accident might happen because you can’t see clearly;
8.To diagnose Light System if you see rapid signal blinking or dimming lights.
And many more …
What Function support?
1:Program the Hidden Functions of the Vehicle
Because of the difference between high and low distribution of vehicles, many low distribution models have hidden high distribution functions, which can bring convenience to car owners.
For example, you can adjust the brightness of the car lights, the horn will sound when the door is locked …. And etc.
Notice:Each car has different hidden functions, the above functions are not specific to each car
2:Activate Test
The process of sending and retrieving information from a vehicle control module with a device is known as Actuation test or bi-directional control. The main aim of the actuation test function is to request the control module to perform a specific function including system tests, actuator tests, functional tests, inspection tests, reprogramming or reinitialization, thus saving diagnostic time.
3: * Read Auto VIN
You can choose the Auto VIN function to scan all systems of all detected vehicles or tap control unit to access a specific system for diagnosis.
4: Manual VIN Input
For vehicles not supporting Auto VIN function, you can manually input the VIN code of the tested car for further diagnosis.
5. 4 Live Data Stream Combine in 1 Graph
Help you find out the problem more easily.
Live Data Stream Graphing
provides very detailed data stream data, it could include the change of Accelerator Pedal Position Sensor1 , Actual Output Shaft Speed , Clutch A Actuator Motor , Vehicle Battery and so on. Graphical data allows you to analyze the data changes of each module more clearly and easily, and it is easier to see the problems in it.
Live Data Stream Record
allow you to record the live data stream and view the data of a certain point in a targeted manner. So that you can view the data more clearly.
Live Data Stream Playback
After you have recorded the data for a period of time, if you want to view and analyze the data just recorded, you need to use data stream playback function to help you. You can view the data at any time you recorded. Then you can choose ” Combine”, ” Report” and ” Record”.
Live Data Stream Sharing
will let you share any data status and content you want to display anytime, anywhere. You can send it to your friend or mechanic to help you solve complex problems.
6: 19 kinds of Special Functions
*Oil/Service/Maintenance Light
Performs reset for the Engine Oil Life system, which calculates an optimal oil life change interval depending on the vehicle driving conditions and climate, and turns off the warning light
*SAS
Performs calibration for the Steering Angle Sensor (SAS), which permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM. On successful completion of the calibration, the steering angle sensor fault memory is automatically cleared
*EPB
Maintains the electronic braking system safely and effectively through deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.
*DPF
carry out numerous functions to the Diesel Particulate Filter system. The tool will manage DPF regeneration, DPF component replacement teach-in and DPF teach-in after replacing the engine control unit
*Headlight
It detects the light of the environment, then decides whether to automatically turn on the headlights or not. It can also adjust the headlights in time
*BMS reset
Re-match the control module and motoring sensor for battery detecting more accurately, clear original low battery information and prevent the related control module from detecting false information
*Tyre Pressure Reset
Relearn TPMS sensors so that new sensors can be recognized by ECU
*ABS bleeding, Airbag Repair, Crankshaft Resync, Injector Coding, Gearbox Match, and more ……..
7: OBD2 Full Function:
This diagnostic software can test vehicle Engine systems.All models with engine meeting SAE J1850,ISO9241-2,ISO14230-4,ISO15765 Standard in OBD2&EOBD.
*View freeze frame date
*support graph data stream
*O2 Sensor test
*Evap system test
*On-Board monitor test
*Read & Clear DTCs
*Identify VIN information
*DTC code look up
*Turn off MIL(Malfunction Indicator Lights)
*I/M Readiness status test
8: What’s More?
1.Remote Diagmosis.
2.Online Diagnostic Report.
3.Community support
4.Dust-Proof shock desgin
9: Multi-language configuration:
ASD60 can support 12 kinds of multi languages:English, Spanish, French. Polish, Russian, Portuguese, German…..you can free switch in the setting.
10: THE OPERATING PROCEDURES:
1. Download and Install APP ASD60 the google play or App store to your device
2. Register and login in the ASD60 app
3. Download all the software of the working
4. Plug the ASD60 Into the Vehicle’s date link connector (obd2)
5. Contact Wirelesswith ASD60 Start the diagnosis
Connection:
ASD60 can plug into vehicle OBD directly or connect to vehicle OBD via extension cable and connect with phone via q.
Report and Replay
*Report shows the diagnostic reports of Live Data or Trouble Codes in the process of diagnosis. Entering Report can check variousdiagnostic reports.
*Replay can check what cars have been tested and play recorded Live Data& freeze frame.
Item Parameter
Model:XTOOL ASD60
Working Voltage: 9~16V
Operating Current:<70mA DC12V
Size: 50.5*47.7*22.5mm
Net Weight: <30g
